Description
Specification
Retcher Cable Cutter (for ACSR & Steel Strand)
| Model | Photo | size | weight | Cutting Range | remark |
| J-13 |  |
345(extend 514)*125*46mm | 1.95kg | ACSR below 720mm² Steel strand below 150mm² forbidden to cut off CU-AL & armored cable |
retractable handle |
| J-30 |  |
406(extend 514*160*60mm | 3.4kg | ACSR below 630mm² Steel strand below 100mm² forbidden to cut off CU-AL & armored cable |
retractable handle |
| J-25 |  |
535(extend 745)*130*60mm | 2.8kg | ACSR below 800mm² Steel strand below 150mm² forbidden to cut off CU-AL & armored cable |
retractable handle |
| J-50 |  |
400(extend 568)*158*52mm | 3.2kg | ACSR below 1440mm² Steel strand below 150mm² forbidden to cut off CU-AL & armored cable |
retractable handle |
Retcher Cable Cutter (for CU-AL & Armord Cable)
| Model | Photo | size | weight | Cutting Range | remark |
| J-40 |  |
346*120*38mm | 1.15kg | CU-AL & armord cable below ∅30mm or 300mm² forbidden to cut off steel cable |
/ |
| J-52 |  |
406(extend 514)*130*60mm | 2.9kg | CU-AL & armord cable below ∅50mm or 500mm² forbidden to cut off steel cable |
retractable handle |
| J-75 |  |
416(extend 587)*200*55mm | 3.6kg | CU-AL & armord cable below ∅75mm or 3*120mm² forbidden to cut off steel cable |
retractable handle |
| J-95 |  |
446(extend 620)*248*55mm | 5.7kg | CU-AL & armord cable below ∅95mm or 3*185mm² forbidden to cut off steel cable |
retractable handle |
| J-100 |  |
490(extend 660)*270*63mm | 6.5kg | CU-AL & armord cable below ∅100mm or 3*300mm² Forbidden to cut off steel cable |
retractable handle |
| J-130 |  |
530(extend 700)*330*63mm | 9.28kg | CU-AL & armord cable below ∅130mm Forbidden to cut off steel cable |
retractable handle |
| J-160 |  |
560(exted 740)*390x59mm | 10.8kg | CU-AL & armord cable below ∅160mm Forbidden to cut off steel cable |
retractable handle |
| XD-520A |  |
330(extend 400)*140*55mm | 1.9kg | CU/AL cable below 300mm² ACSR below 32mm Steel bar below φ10mm Steel wire rope φ8-16mm |
retractable handle |
