Fixed Joint
1T 3T 5T 8T Stringing Equipment Accessories U-shaped Wire Anti-bending Connector
- The connectors are specifically designed to connect pilot rope lengths or pulling rope lengths and to pass over the puller bull wheels. They are made of highly tensile galvanized steel.
Product Spec
| Model | Capacity(kN) | Open Size(mm) | Total Length(mm) | Weight (kg) | Surface Treatment |
| 1T | 10 | 14 | 68 | 0.2 | Electrio-galvanized |
| 3T | 30 | 17 | 76 | 0.22 | Electrio-galvanized |
| 5T | 50 | 19 | 96 | 0.6 | Electrio-galvanized |
| 8T | 80 | 22 | 110 | 0.8 | Electrio-galvanized |
Detail Images
